Venlo Multi Span Custom Glass Greenhouse For Vegetables Farming Growing

Venlo Multi Span Custom Glass Greenhouse For Vegetables Farming Growing

Product description

Glass greenhouse refers to a greenhouse that uses glass as lighting material,

which belongs to a kind of greenhouse.

In cultivation facilities, glass greenhouse, as a form with the longest service life,

is suitable for use in various regions and various climatic conditions.

The industry is divided into different construction models according to the size of the span and bay,

and is divided into different types of use: vegetable glass greenhouses, flower glass greenhouses,

nursery glass greenhouses, ecological glass greenhouses, scientific research glass greenhouses,

three-dimensional glass greenhouses, special-shaped glass greenhouses Glass greenhouses,

leisure glass greenhouses, smart glass greenhouses, etc.

The area and use method can be freely adjusted by the greenhouse owner.

The smallest is a courtyard leisure type. The largest height can reach more than 10 meters,

the span can reach 16 meters, and the maximum bay can reach 10 meters. The degree of intelligence can reach one-key control.

Product Name	Sainpoly venlo glass greenhouse from China
Materia	Hot Dipped Galvanized Steel Pipe,diameter is 25mm,32mm,40mm,42mm,50mm,60mm
Covering material	Single glass or double glass
Length	30-60m or customized
Span width	9.6m,10.8m,12m or customized
Roof height	3-6m or customized
Wall height	3.5m or customized
Wind Load	0.6KN/㎡
Snow Load	0.5KN/㎡

Option system

Shading system

Inner sunshade mounted on lower suspension and truss beams (distributed on top only) Silver aluminum foil material, white polyester rope fixed 65% blackout rate (two white and one transparent) It works by reflecting light

The outer sunshade is fixed above the greenhouse frame and supported by columns and beams

Made of black round wire, fixed with black polyester rope Shading rate 75%, mostly used in hot and dry areas The working principle is to absorb

and mask light

Drip irrigation

The spacing of drip irrigation belts is generally placed at 0.8m

Cooling system



The operation principle of the cooling system is that the fan is installed in the inner side of the greenhouse, and the air is discharged to generate negative pressure in the room. The air on the other side enters the room after cooling through the wet curtain, and the wet curtain has a pump to provide flowing water for cooling and humidifying.



Our certificate

Packing and Delivery

FAQ

Q1:Are you a trading company or a manufacturer?

A: We are a factory. Our factory produces all items related to the greenhouse, so we provide the best price.

Q2: Do you provide samples? Is it free or extra?

A: Yes, we can provide samples free of charge, but we don't bear the freight.

Q3: How should I choose a greenhouse system?

A: Please let us know where the greenhouse is (temperature, wind speed)

Q4: How to assemble the greenhouse when purchasing?

A:We have professional after-sales service engineers who will provide planning drawings and installation manuals. You can communicate with him from time to time.
